Electric Outdoor High Voltage Disconnect Switch 12kv 2000A Max Current

XK Factory price high voltage 12kv outdoor disconnect switch

Hot sale 40.5KV outlinedoor H.V. disconnecting switch

Product Description

Using Environment

1. The temperature in surrounding air: Max:+40°C~Min -15°C,The average:<=+35°C
2. Humidity: The average of relative temperature within 24hours is <=95%, The average of Water
vapour pressure within 24hours is <=2.2kpa.
3. Here is no serious pollution from dust, smoke,corrosive or combustible gas,
vapor or salt spray, and so on.

Electric Outdoor High Voltage Disconnect Switch 12kv 2000A Max Current

Item			Unit	Data
Rated voltage			KV	40.5/72.5/126
Rated lnsulating level	1min power fequncy voltage withstand	To earth	KV	95/140/230
		Fracture	KV	115/160/245
	lmpulse voltage withstand	To earth	KV	185/325/550
		Fracture	KV	215/375/630
Rated frequency			HZ	50
Rated current			A	630/1250/1600/2000
Rated short time current withstand			KA	20/31.5/40/40
Rated peak current withstand			KA	50/80/100/100
Rated short circuit cont.current:Mian/earth blade			S	4/2

Rated teminal mechanical load		Vertical	N	750/1000
		Horizontal	N	500/750
		Vertical Force	N	750/1000
Creepage distance			MM	1013/1256,1813/2248,3150/3906
Mechanical life			Times	2000
Manual operating mechanism	Model			CS17,CS17G
	Voltage of control circuit		V	AC220 DC110 DC220
Electic operating mechanism	Voltage of motor		V	AC380 DC220 DC220
	Voltage of control circuit		V	AC220 DC110 DC220

Rated volt	A	A1	H	E	C	D
40.5	1200	1075	1070	1400	240	300
72.5	1600	1285	1295	2200	240	300
126	2000	1660	1695	3000	240	300
